Panasonic WJ-GXD400 Network Video Decoder

The Panasonic WJ-GXD400 Network Video Decoder works with the Panasonic Megapixel i-Pro Network Surveillance System to provide high definition security video. Using an HDMI video interface, it decodes MPEG-4 and JPEG image data to provide 30 or 25 fps video for up to 6 split screens, so you never miss a thing.

Register up to 256 cameras and encoders with the Panasonic WJ-GXD400 Multi Channel High Definition Video Decoder to increase the coverage of the IP surveillance camera system. It supports camera site alarm signaling for added security and multicast/unicast for increased efficiency.

Panasonic WJ-GXD400 Network Video Decoder Quick Specs:

• Supported Cameras: Panasonic i-Pro series
• Supported Encoders: Panasonic i-Pro series
• Supported Image Formats: MPEG-4, JPEG
• Resolution: 1x 4VGA (1280x960), 2x or 6x VGA
• Video Interface: HDMI
• Video Output: 1x NTSC or PAL composite video signal
• Protocols: HTTP, TCP/IP, UDP/IP, etc.
• Network Connector: 10Base-T/100Base-TX RJ-45
• PoE: N/A
• Addtâ l Ports: 1x RCA pin jack, 1x BNC connector
• Operating Temp.: 14°F - 122°F

Panasonic WJ-GXD400 MPEG-4/JPEG High Definition Video Decoder Package Contents:

• Panasonic WJ-GXD400 video decoder
• Operating instructions and CD
• Power cord plug
• Code label
• AC adapter (for installation)
