Viking ES-1 Door Controller Entry System

Viking ES-1 door entry controller allows the programming of up to 250 unique tenant codes to allow proximity card entry to buildings. This device is perfect for a single-door entry at almost any business, residence, or commercial building. Easily connect a door strike or magnetic lock directly to this module. Use this device with card readers, digital keypads, and transmitters that output 26-bit Wiegand.

Program up to 3 ES-1 controllers at the same time for seamless deployments in locations with multiple doors and even connect two Wiegand devices to an ES-1 for entry and exit control! Entry logs, one-time code for visitors, and a non-volatile memory make the ES-1 door entry controller a versatile proximity reader.

© 2022 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Viking ES-1 Door Controller Quick Specs:

• Tenants: up to 250 supported
• Wiegand Device: 26-bit compliant
• Connections: 11x screw terminals, RJ11 telco jack
• Relay Contact Ratings: max. 5A @ 30V DC/250V AC
• Max. Wiegand Length: 500 ft - 24 AWG
• Max. LOG BUS Length: 5280 ft/1 mile - 24 AWG
• Dimensions: 5.25" x 3.5" x 1.75"

Viking Electronics ES-1 Entry System Package Contents:

• Viking ES-1 module
• 12V power adapter

Viking ES-1 Documentation:

• Viking ES-1 Product Manual
