Aiphone IX-DVM Mullion-Mount IP Video Door Station

Aiphone IX-DVM is a compact HD video door station intended for mounting in mullions — perfect for door frames. Measuring not even 2 inches wide, IX-DVM still packs in a 720p HD camera and easy to use, backlit call button. The video intercom has a sensor to enable contactless calling — improve sanitation. IX-DVM is weather and vandal resistant — meets the IP54 and IK07 durability standards.

As an IP intercom, IX-DVM runs the open SIP communications protocol, making it usable on numerous IP phone systems and cloud phone services. Make IX-DVM part of an access control solution using the contact output — for a door strike or other peripheral. You can record video to an internal microSD card (not included) for additional security. IX-DVM is ONVIF Profile S compliant — interoperable with third-party devices.

© 2022 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Aiphone IX-DVM Quick Specs:

• Camera: 720p HD
• Field of View: ~170°
• Edge Storage: microSD
• Physical Connectors:
• Ethernet: RJ45 PoE
• Relays: 1x contact output, 1x input
• PoE (Power Over Ethernet): 802.3 af Class 0
• ONVIF: Profile S
• Operating Temperature: -40°F to +140°F
• Durability Ratings: IP54, IK07
• Dimensions:
• Height: 6.88 in
• Width: 1.88 in
• Depth: 1.31 in

Aiphone IX-DVM VoIP Video Intercom Package Contents:

• IX-DVM Door Station
• Mounting Frame (attached to unit)
• Installation Hardware
• Option Connector
• Installation Manual

Aiphone IX-DVM Documentation:

• Aiphone IX-DVM Datasheet
• Aiphone IX-DVM Installation Manual
