Algo 8186 Outdoor SIP Horn Speaker

Algo 8186 is a weatherproof horn speaker for paging or intercom with SIP and Multicast support. Algo 8186 features a three-axis rotation design with included mounting bracket and sealing gaskets, which means you can install this loudspeaker almost anywhere at almost any angle you need. The 8186 can be mounted on the wall, ceiling or double gang electrical box. It connects to your LAN via Ethernet cable, and is PoE compliant, so you can power it with a PoE injector or switch. With SIP support, managing the Algo 8186 as part of a system is much easier than traditional paging speakers.

Algo 8186 has a wideband frequency response range of 350 Hz to 9 kHz, so your pages will be loud and clear. An integrated microphone monitors ambient noise to allow the speaker to automatically compensate for the environment. The horn shape focuses the sound dispersion to provide louder, more directed audio. Algo 8186 is IP66 rated, making it suitable for outdoor and wet environments. It has an operating temperature range of -40°F to 122°F.

Algo 8186 Speaker Quick Specs:

• Communications Protocol: SIP
• PoE: 802.3af Class 0
• Sensitivity: 110 dBA @ 1m
• Dispersion Angle: 76°H x 51°V
• Microphone: electret omnidirectional wideband
• Audio Codecs: G.711μ/a, G.722, Polycom Group Page, OGG Vorbis
• Operating Temperature: -40°F - 122°
• Durability Ratings: IP66

Algo 8186 SIP Double Re-entrant Loudspeaker Package Contents:

• Algo 8186 Speaker
• Mounting bracket
• Gaskets

Algo 8186 Documentation:

• Algo 8186 Product Sheet
• Algo 8186 Installation and User Guide
• Algo SIP Endpoint Provisioning Guide
• Algo SIP Endpoint Registration Guide
