Axis Camera Station S2216 Mk II Rack Appliance - 02809-004

Axis Camera Station S2216 Mk II is a powerful IP camera solution: a combination PoE switch and NVR. Intended to be rack-mounted, S2216 Mk II is a 16-port network switch with 260 W PoE power budget and network video recorder with support for up to 16 channels. The appliance comes with 16 Axis Camera Station Pro Core Device NVR licenses (tied to the hardware) that are pre-installed. You can upgrade it with additional licenses. S2216 Mk II also comes with professional software like Axis Recorder Toolbox pre-installed. It supports advanced AI applications like Smart Search 2 to make your video evidence more usable. Put together, S2216 Mk II is a streamlined solution for establishing a professional IP security camera system. And it also provides exceptional system security with features like a FIPS 140-2 Level Certified TPM.

As a recorder, Axis S2216 Mk II has a generous 8 TB of storage out of the box (2x 4 TB HDD) with an additional two slots for more storage. It supports RAID Levels 0, 1, and 10 for network attached storage. As a computer, it runs Windows 11 IoT Enterprise and has an Intel Core i3 CPU. With two HDMI 2.1 ports, you can connect S2216 Mk II to two HD displays at the same time for viewing recordings and for live view. S2216 Mk II supports up to one 4K Ultra HD feed (four 1080p Full HD feeds) via a Windows client or even one 8K video feed via a local or remote web client. As a PoE switch, it has 16 Gigabit Ethernet ports with PoE support, which means you can connect and power IP cameras and other network devices using the same device. It has a 260 W total power budget.

© 2025 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis S2216 Mk II Quick Specs:

• Licenses: includes 16 Axis Camera Station Pro Core Device NVR licenses (tied to hardware)
• System Scalability: up to 16 video channels and 32 doors
• OS (Operating System): Microsoft Windows 11 IoT Enterprise LTSC 2024
• CPU (Processor): Intel Core i3
• RAM (Memory): 16 GB DDR5 (2x 8 GB)
• Hard Drive Slots: 4x total (2x free)
• Hard Drive (Storage): 8 TB included (2x 4 TB)
• RAID: supports RAID Levels 0, 1, 10 (not configured)
• Physical Connectors (Front):
• USB: 2x USB-A 3.2
• Audio: 1x 3.5 mm
• Physical Connectors (Back, Switch Side):
• Ethernet (Out): 16x Gigabit RJ45 PoE
• Ethernet (In): 1x Gigabit RJ45
• SFP: 1x Gigabit SFP
• Physical Connectors (Back, Server Side):
• Ethernet: 1x Gigabit RJ45
• USB: 2x USB-A 2.0
• HDMI: 2x HDMI 2.1
• PoE (Power Over Ethernet): 802.3at Class 4
• PoE Power Budget: up to 260 W

Axis Camera Station S2216 Mk II Rack Appliance Package Contents:

• Appliance
• Rack Rails
• Power Cord

Axis S2216 Mk II Documentation:

• Axis S2216 Mk II Datasheet
