Axis F9114-R Mk II 4-Channel Main Unit - 02999-001

Axis F9114-R Mk II is a 4-channel main unit for use with compatible Axis F Series sensor units for covert surveillance. F9114-R Mk II offers up to 4K Ultra HD resolution, giving you incredibly detailed video to protect premises, vehicles, ATMs, and more. The main unit expands its security offerings with two 3.5 mm audio inputs for connecting external microphones. By handling 4 sensor units from one device, you can establish a truly professional surveillance system with a minimum of fuss.

F9114-R Mk II is a cutting-edge camera main unit with a purpose-built ARTPEC-8 System on a Chip that has a deep learning processing unit. This processing power lets it supportAI-enhanced analytics, including Axis Object Analytics, which is already installed on the device. Object Analytics is a suite of solutions for automatically detecting, classifying, tracking, and counting humans and vehicles. Also installed on device is Axis Sensor Metrics Dashboard, which enables data collection from GPS, accelerometer, or Modbus sensors. It can store this data locally in the main unit on a microSD card, making it an excellent solution for mobile surveillance. The main unit is protected by Axis Edge Vault, a hardware-based cybersecurity platform with a deep suite of security measures incorporated from the ground up. It protects main unit and the other devices on your system. F9114-R Mk II handles rough installations with an aluminum casing that's shock and vibration resistant.

© 2025 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis F9114-R Mk II Quick Specs:

• System on a Chip: ARTPEC-8
• Video Compression: H.264 (AVC) Baseline, Main, High; H.265 (HEVC) Main; Motion JPEG
• Video Resolution: up to 4K Ultra HD (3840 x 2160 px)
• Frame Rate: up to 60 fps
• Audio Input: 2x inputs for external microphones
• Physical Connectors:
• Ethernet: Gigabit RJ45 PoE
• FAKRA: 4x for sensor units
• I/O: 6-pin terminal block for 4x configurable I/Os
• Audio: 2x 3.5 mm mic/line in
• Serial: 2-pin terminal block RS485
• Power: 3-pin terminal block
• USB: 1x USB-A
• PoE (Power Over Ethernet): 802.3af/at Type 2 Class 4
• Durability Standard: IP3X

Axis F9114-R Mk II Main Unit Package Contents:

• Main Unit
• Installation Guide

Axis F9114-R Mk II Documentation:

• Axis F9114-R Mk II Datasheet
• Axis F9114-R Mk II Installation Guide
