Axis P9117-PV 6 MP Corner-Mount Panoramic IP Camera - 02864-001

Axis P9117-PV is a panoramic IP camera designed for indoor mounting in corners. As a corner-mount camera that meets the IK10 rating, it is vandal-resistant and prevents ligatures from being attached to it. The camera provides 360° coverage using a stereographic lens and 6 MP sensor, giving you the professional detail on your surveillance video that you require for protection. It has a built-in microphone for an extra dimension of security. Audio Analytics comes pre-installed.

P9117-PV has a deep learning processing unit (DLPU), which means it can run advanced analytics on the edge. Object Analytics comes installed on the camera, which can automatically classify objects that the camera sees. It uses Lightfinder technology to improve video quality in extreme low-light, giving the video naturalistic color beyond what the human eye can perceive. It also uses Forensic WDR to deal with extreme contrast. Store video in camera using a microSD card or through the network using a NAS or NVR solution. P9117-PV is ONVIF Profile G, M, S, and T compliant. For extra vandal-resistance, search for the Axis TP9801 Stainless Steel Cover (available separately).

© 2024 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis P9117-PV Quick Specs:

• System on a Chip (SOC): ARTPEC-8
• Image Sensor: 1/1.8” progressive scan RGB CMOS
• Video Resolution (Corner View): up to 2048 × 1152 px
• Frame Rate: up to 60 fps
• Video Compression: H.264 (AVC) Baseline, Main and High; H.265 (HEVC) Main; Motion JPEG
• Lens: fixed 1.1 mm, f/2.2
• Field of View (Corner View):
• Horizontal: 115°
• Vertical: 100°
• Camera Angle Adjustment:
• Digital Roll: ±180°
• Minimum Illumination:
• Color: 0.17 lux
• B/W: 0.04 lux
• Audio: 2-way (full duplex)
• Physical Connectors:
• Ethernet: 10/100 RJ45 POE
• Audio and I/O: via portcast technology
• Power Over Ethernet (POE): 802.3af/at Type 1 Class 3
• Edge Storage: microSD, microSDHC, microSDXC
• ONVIF Profiles: G, M, S, T
• Operating Temperature: 5°F to 122°F
• Durability Ratings: IP66, IK10
• Dimensions:
• Height: 3.62 in
• Width: 5.75 in
• Depth: 4.80 in
• Weight: 1.68 lb

Axis P9117-PV Corner-Mount Network Security Camera Package Contents:

• P9117-PV Camera
• Installation Guide
• RJ45 Tool Mounting
• Extra Screw Gaskets
• Extra Cable Gasket
• Owner Authentication Key

Axis P9117-PV Documentation:

• Axis P9117-PV Datasheet
• Axis P9117-PV Installation Guide
