Axis Q1659 20MP 100mm f/2.8 Lens IP Camera - 0966-001

Axis Q1659 is a professional IP security camera that uses a Canon EF lens and Canon APS-C sensor to give you class-leading 20MP surveillance video. This package comes with a Canon EF 100mm telephoto lens with a fast f/2.82 aperture. Q1659 brings the quality of a top-end Canon DSLR camera to installed video surveillance. You get unparalleled video resolution up to 5472x3648 video at 8 frames per second or 4k Ultra HD 3840x2160 video at 25 frames per second. Axis Zipstream retains important detail, while saving you a lot on bandwidth and storage. When you absolutely need detailed evidence, you can't find a better security camera!

Axis Q1659 has a Gigabit Ethernet port and is PoE compliant for power via PoE injector or switch. Alternately, you can use an optional IP67-rated Axis PS24 240W adapter for power. For more bandwidth, connect a fiber optic cable using the SFP slot. Store video locally using a microSD, microSDHC, or microSDXC card. With Axis, you get the full compliment of security and QoS features for professional deployments. Compatible with a wide range of video management software platforms, the Q1659 is also ONVIF-S and -G compliant. For the more reliable outdoor installation, get the optional Axis T93C10 housing and Axis T93C wall-and-pole conduit back box. Axis includes a 3-year manufacturer warranty.

Axis Q1659 IP Camera Quick Specs:

  • Image Sensor: 22.4 x 15.0mm APS-C CMOS
  • Lens: Canon EF 100mm, f/2.8
  • Infrared: removable automatic infrared cut filter
  • Field of View: 12.8° H at 20MP, 9.0° H at 4k
  • PTZ: digital
  • Video Codecs: H.264 High, Main & Baseline, Motion JPEG
  • Resolution: up to 5472x3648 (20MP)
  • Frame Rate: 8 fps at 20MP, 25 fps at 4k
  • Audio: two-way
  • Audio Codecs: AAC-LC 8/16/32/48 kHz, G.722, G.726, Opus
  • Ethernet Port: 1x 10/100/1000 Gigabit
  • PoE: 802.3af/at Type 2 Class 4
  • Fiber Port: 1x 100/1000 SFP
  • Additional Ports: 3.5mm line-in/out, RS485/RS422, terminal block for 2 inputs/outputs
  • Edge Storage: microSD, microSDHC, microSDXC
  • ONVIF: ONVIF-S/G
  • Operating Conditions: 32°F - 122°F
  • Casing: aluminum
  • Dimensions (camera body): 7" x 4" x 3"

Axis Q1659 20MP IP Surveillance Camera with Canon Lens Package Contents:

  • Q1659 camera body with body cap
  • Canon EF 100mm f/2.8 lens
  • 2-pin connector block for power input
  • 4-pin I/O connector block for connecting external devices
  • 2x 2-pin RS485/422 connector block
  • Installation guide
  • 2x extra serial number label

Warranty:
3 Years
