Axis Q1798-LE 4k/10MP IR Outdoor Bullet IP Camera - 01702-001

Axis Q1798-LE is a powerful, elite surveillance camera that offers 4k Ultra HD video using a professional Canon lens. Q1798-LE uses a large, ultra high sensitivity 4/3" back-illuminated sensor to provide either 10MP video at a 4:3 ratio or 4k UHD video at a 16:9 ratio with much less noise than a smaller sensor could provide. The Canon varifocal 12-48mm lens with a maximum aperture of f/1.7 for crisp detail and tremendous light performance. Combine that lens with Lightfinder 2.0, which enables naturalistic coloration in extreme low-light, and onboard infrared lights with an unbeatable range of 100m (328ft) for no-light surveillance. Q1798-LE is perfect for airports, harbors, stadiums, arenas, industrial campuses, and similar environments.

Axis Q1798-LE is a network-connected camera with progressive features to improve your security. Forensic WDR intelligently adapts to high-contrast lighting to greatly reduce under- and overexposure. OptimizedIR configures the power-efficient infrared LEDs to specific installations, giving you ideal coverage no matter the installation. H.265 video compression reduces bandwidth and storage load by up to 50% or more. Store video in camera using a microSD card or through the network using an network video recorder or NAS solution. Q1798-LE is rated for outdoor installation. It is IP66/67 rated against dust and water ingress and IK10 rated against impacts, making it vandal-resistant. It has an extended operating temperature range of -40°F to 140°F. Q1798-LE is ONVIF Profile G, Profile S, and Profile T compliant.

Axis Q1798-LE IP Camera Quick Specs:

• Connectivity Type: IP
• Ethernet Ports: 1x Gigabit
• PoE: 802.3at Type 2 Class 4
• Additional Interfaces:
• IDC punchdown connector
• AC and DC power connector
• Terminal block for two configurable supervised inputs / digital outputs
• 3.5mm mic/line in
• Sensor: 4/3" back-illuminated color CMOS
• Resolution:
• 10MP: 3712x2784 @ 20fps
• 4k: 3840x2160 @ 30fps
• Zoom: 4x optical
• Video Codecs: H.264 Baseline, Main, High; H.265 (HEVC) Main; MJPEG
• Lens: Canon varifocal 12-48mm, f/1.7-4.0
• Field of View:
• 10MP: 86°-20° H x 62°-15° V
• 4k: 90°-21° H x 49°-12° V
• Minimum Illumination: 0.03 lux color, 0.006 lux b/w, 0 lux IR
• Infrared Range: 50m (164ft) wide, 100m (328ft) tele
• Audio: audio in, simplex
• Audio Codecs: AAC-LC, G.711, G.726, Opus, LPCM
• Edge Storage: microSD, microSDHC, microSDXC
• Operating Temperature: -40°F - 140°F
• ONVIF: Profile G, Profile S, Profile T
• Durability Ratings: IP66/67, IK10, NEMA 250 Type 4X

Axis Q1798-LE Network Security Camera Package Contents:

• Axis Q1798-LE IP Camera
• Installation Guide
• Windows Decoder 1-User License
• Connector Kit
• Resistorx L-Key
• RJ45 Patch Cable
