Axis Q9216-SLV 4MP IR Vandal Anti Ligature Corner Mount IP Camera, Steel - 01766-001

Axis Q9216-SLV is a stainless steel IP camera that resists ligatures. The camera's rugged, corner mounted design reduces opportunities for self harm and vandalism for installation in highly sensitive environments like psychiatric wards and prisons. As a surveillance camera, it takes highly detailed 4MP video using a professional CMOS sensor. The wide angle lens covers the entire scene to ensure that no corner is missing. Polygonal privacy masking allows you to maintain subject privacy. The built-in infrared lights offer discreet surveillance even in pitch black conditions.

Axis Q9216-SLV comes with enhanced security features to protect the camera system, like signed firmware and secure boot. The camera has a Trusted Platform Module for private storing all passwords and certificates, even in the event of a security breach. It uses Wide Dynamic Range (WDR) technology to deal with high contrast lighting, like strong shadows or sunlight through windows. H.265 video compression plus Axis Zipstream greatly improve the efficiency of the video feed to reduce storage and bandwidth load. Store video in camera using a microSD card or through the network using an NVR or NAS solution. The camera is IP66 rated against dust and water ingress and IK10+ rated against impacts and vandalism. The stainless steel casing is IP6K9K rated to allow cleaning with high pressure, high temperature water jets. Axis Q9216-SLV is ONVIF Profile G, Profile S, and Profile T compliant.

Axis Q9216-SLV IP Camera Quick Specs:

• Connectivity Type: IP
• Ethernet Ports: 1x 10/100
• PoE: 802.3af/at Type 1 Class 3
• Additional Connectors:
• I/O: 4-pin 2.5 mm terminal block for 1 supervised digital input and 1 digital output
• Audio: 3.5 mm mic/line in, 3.5 mm line out
• HDMI: Type D
• Sensor: 1/2.5" progressive scan RGB CMOS
• Resolution: up to 4MP @ 30fps
• Video Codecs: H.264 Main, High; H.265 Main; Motion JPEG
• Lens: fixed 2.4 mm, f/2.0
• Field of View:
• Horizontal: 125°
• Vertical: 95°
• Minimum Illumination:
• Color: 0.23 lux
• B/W: 0.05 lux
• Infrared: 0 lux
• Infrared Range: 49 ft (15 m)
• Audio: two-way, full duplex
• Audio Codecs: LPCM, AAC-LC, G.711, G.726, Opus
• Edge Storage: microSD, microSDHC, microSDXC
• ONVIF: Profile G, Profile S, Profile T
• Operating Temperature: -4°F to 122°F
• Durability Ratings: IP66, IP69, IP6K9K, IK10+, NEMA 4X
• Dimensions:
• Height (when corner mounted): 4.57 in
• Depth (when corner mounted): 5.83 in
• Weight: 3.5 lb

Axis Q9216-SLV Network Security Camera Package Contents:

• Axis Q9216-SLV IP Camera
• Installation Guide
• Windows Decoder 1-User License
• AVHS Authentication Key
• Axis Device Microphone A
• Axis Connector A 4-pin 2.5 Straight
• Cable Gaskets
• Resistorx 20 Bit
