Axis Q9216-SLV 4MP IR Vandal Anti-Ligature Corner-Mount IP Camera, White - 01767-001

Axis Q9216-SLV is a rugged, compact IP camera that resists ligatures. Q9216-SLV mounts in corners with no blind spots. The corner mounted design and ruggedized casing reduce the possibility of self harm and vandalism, making it ideal for mounting in highly sensitive locations like psychiatric wards and prisons. The camera uses a professional CMOS sensor to offer highly detailed 4MP surveillance video — twice the resolution of a 1080p Full HD camera. The wide angle lens has a broad field of view, which means no spot will go unseen. The camera includes onboard infrared lights for discreet surveillance in complete darkness. Polygonal privacy masking gives subjects privacy.

Axis Q9216-SLV features enhanced security functionality like signed firmware and secure boot to protect your security camera system. In addition, it has a Trusted Platform Module that securely stores all passwords and certificates, even in the event of a security breach. Q9216-SLV features Wide Dynamic Range (WDR) technology to reduce the impact of high contrast lighting, like strong shadows or sunlight through windows. H.265 video compression plus Axis Zipstream make the video feed ultra-efficient, greatly reducing storage and bandwidth load. Store video in camera using a microSD card or through the network using an NVR or NAS solution. The camera is IP66 rated against dust and water ingress and IK10+ rated against impacts and vandalism. Axis Q9216-SLV is ONVIF Profile G, Profile S, and Profile T compliant.

Axis Q9216-SLV IP Camera Quick Specs:

• Connectivity Type: IP
• Ethernet Ports: 1x 10/100
• PoE: 802.3af/at Type 1 Class 3
• Additional Connectors:
• I/O: 4-pin 2.5 mm terminal block for 1 supervised digital input and 1 digital output
• Audio: 3.5 mm mic/line in, 3.5 mm line out
• HDMI: Type D
• Sensor: 1/2.5" progressive scan RGB CMOS
• Resolution: up to 4MP @ 30fps
• Video Codecs: H.264 Main, High; H.265 Main; Motion JPEG
• Lens: fixed 2.4 mm, f/2.0
• Field of View:
• Horizontal: 125°
• Vertical: 95°
• Minimum Illumination:
• Color: 0.23 lux
• B/W: 0.05 lux
• Infrared: 0 lux
• Infrared Range: 49 ft (15 m)
• Audio: two-way, full duplex
• Audio Codecs: LPCM, AAC-LC, G.711, G.726, Opus
• Edge Storage: microSD, microSDHC, microSDXC
• ONVIF: Profile G, Profile S, Profile T
• Operating Temperature: -4°F to 122°F
• Durability Ratings: IP66, IP69, IK10+, NEMA 4X
• Dimensions:
• Height (when corner mounted): 4.57 in
• Depth (when corner mounted): 5.83 in
• Weight: 3.5 lb

Axis Q9216-SLV Network Security Camera Package Contents:

• Axis Q9216-SLV IP Camera
• Installation Guide
• Windows Decoder 1-User License
• AVHS Authentication Key
• Axis Device Microphone A
• Axis Connector A 4-pin 2.5 Straight
• Cable Gaskets
• Resistorx 20 Bit
