Axis V5938 4K Ultra HD PTZ Live Streaming Camera - 02023-004

Axis V5938 is a 4K Ultra HD camera for broadcast quality video — perfect for web casting from auditoriums, classrooms, board rooms and similar locations. V5938 is a full PTZ camera with 20x optical zoom plus 12x digital — up to 240x total zoom. Connect it to an HD display using HDMI — and it supports 3D-SDI. The live streaming camera has a powerful chipset — run analytics on the camera itself.

In addition to exceptional video quality, V5938 offers exceptional audio quality with XLR inputs with 48V phantom power — use it with studio grade microphones. Or use the 3.5 mm jacks for convenient connectivity. The VISCA connection lets you integrate the camera with an existing audio/video system — and it supports VISCA Over IP for camera control through the IP network. V5938 supports H.265 video compression — ultra efficient. And it provides exceptional security with features like signed firmware and secure boot. Axis V5938 is ONVIF Profile G and Profile S compliant — interoperable with third party systems.

© 2021 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis V5938 Quick Specs:

• Sensor: progressive scan RGB 1/2.5" CMOS
• Lens: varifocal 4.4-88 mm, f/2.0-3.8
• Field of View:
• Horizontal: 70.2° to 4.1°
• Vertical: 39.5° to 2.3°
• Minimum Illumination:
• Color: 0.7 lux
• B/W: 0.06 lux
• PTZ:
• Pan: -170° to +170°
• Tilt: -20° to 90°
• Zoom: 20x optical, 12x digital; 240x total
• Video Compression: H.264 Baseline, High, Main; H.265 Main; Motion JPG
• Resolution:
• HDMI Output: up to 4K Ultra HD at 30 fps; up to 1080p at 60 fps
• SDI Output: up to 1080p at 60 fps
• Audio: two-way stereo
• Physical Connectors:
• Ethernet: Gigabit RJ45
• Audio: 3.5 mm stereo line in, 3.5 mm stereo line out
• XLR: XLR-3 line in with 48V phantom power
• HDMI: HDMI Type A, BNC for SDI
• RS232: RS232 serial connector for VISCA
• Terminal Block: 1 alarm input, 1 output
• Internal Storage: microSD, microSDHC, microSDXC
• ONVIF: Profile G, Profile S
• Dimensions:
• Height: 7.1 in
• Diameter: 5.4 in
• Weight: 3.3 lb

Axis V5938 PTZ Network Camera Package Contents:

• V5938 Camera
• Power Supply
• Wall/Ceiling Mount
• Terminal Connector for I/O
• Installation Guide
• Windows Decoder User License
• Camstreamer 3-Month Trial

Axis V5938 Documentation:

• Axis V5938 Datasheet
• Axis V59 Series Installation Guide
