Bogen TPU15A Telephone Paging Amplifier

Bogen TPU15A is a 15W analog paging amplifier that is designed to be wall-mounted. Compact and feature-rich, it supports automatic level control to equalize varying channel inputs so different volume levels will sound great. It also supports voice-activated muting of music when a page is being broadcasted, so it'll be heard clearly, as well as a night ringer.

TPU15A has input terminals for a 600-Ohm balanced telephone line, background music source, and dry contacts for the night ringer. Its output terminals can connect to 70V, 25V, and 8-Ohm speakers. Adjust the controls (paging, music, night ringer, amp tone) using a screwdriver. To protect your system, it has an overload indicator and low-cut switch.

© 2024 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Bogen TPU15A Quick Specs:

• Rated Output Power: 15W
• Inputs:
• Music: Hi-Z AUX, 25 Kilohms, unbalanced
• Page: 600 Ohms, balanced, transformer isolated
• Night Ringer: steady tone while dry contacts are closed
• Outputs: 8 Ohm/25V/70V balanced, transformer coupled
• I/O Connections: screw terminals

Bogen TPU15A Telephone Paging Amplifier Package Contents:

• Amplifier

Bogen TPU15A Documentation:

• Bogen TPU15A Datasheet
• Bogen TPU15A Manual
