Bogen TPU60B Telephone Paging Amplifier
$1,067.53
$459.99
(You save
$607.54
)
- SKU:
- TPU60B
- UPC:
- 765368200935
- Condition:
- New
- Availability:
- Usually Ships Same Business Day
- Shipping:
- Calculated at Checkout
- Warranty:
- 2 Year
Have a question?
-
Industry Best Pricing
Quantity discounts available
-
Friendly Associates
Pre-sales product and solution advice
-
Expert Tech Support
Add-on tech support plans available
-
Super Fast Delivery
Same day shipping on most orders
Bogen TPU60B Telephone Paging Amplifier
$1,067.53
$459.99
(You save
$607.54
)
Bogen TPU60B is a 60W telephone paging amplifier that is designed for wall mounting to make your paging system cleaner and more functional. An analog paging amp, TPU60B enables paging from a telephone or microphone. The amplifier also supports music input for background music reproduction. Its Audio Enhancement circuit improves audio reproduction. The amp's automatic voice-activated, variable level, music mute function lets everyone hear voice pages clearly. The music will then fade back gently after the voice page is over.TPU60B includes night ringer functionality. Double the input/output power by bridging two TPU amplifiers.
TPU60B has numerous I/O connections. It has input terminals for a 600-Ohm balanced telephone line, Lo-Z balanced microphone, and background music, and output terminals for 70V and 25V speakers. It has individual controls for telephone/microphone paging volume, music volume, night ringer volume, VOX sensitivity, and music mute level. The wall-mounting brackets are pre-attached to streamline installation. While TPU60B is intended to be wall-mounted, it can be rack-mounted using the Bogen RPK82 Rack Mount Kit (not included).
© 2024 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.
Bogen TPU60B Quick Specs:
- Rated Output Power: 60W RMS
- Inputs:
- TEL: 600 Ohms, balanced, transformer isolated
- Music: Hi-Z AUX, RCA jacks or screw terminals
- MIC: Lo-Z balanced, screw terminal connection
- Music Mute: mutes music when shorted
- Contact Ring: sounds night ringer tone when customer-supplied dry contacts are closed
- TEL Ring: sounds night ringer in response to 90V ring signal
- Bridging: permits bridging of two amplifiers
- Outputs: 25V/25VCT/70V, 16 Ohms balanced or unbalanced
- Overhead Protection: 1.6A
Bogen TPU60B Telephone Paging Amplifier Package Contents:
- Amplifier
- 4x Wall-Mounting Screws with Synthetic Washers
- 4x Rubber Feet with Screws
- Installation and Use Manual
