Cisco Meraki MS225-24P 24-Port 370W PoE+ Cloud-Managed Gigabit Switch

Cisco Meraki MS225-24P is a cloud-managed stackable switch for enterprise with Gigabit Ethernet speed and 24 ports of PoE+ power. Cisco MS225-24P features 24 Gigabit RJ45 ports with PoE+ support for copper with four 10 Gigabit SFP+ uplink ports for fiber. MS225-24P supports 802.3af PoE with 15.4W of power per port or 802.3at PoE+ with 25.5W per port. It has a maximum output of 370W. The network switch has a 128 Gbps switch capacity and gives you up to 80 Gb physical and virtual stacking.

Cisco Meraki MS225-24P-HW includes voice and video QoS control for optimizing data traffic. With MS225-24P, you get the incredible reliability and engineering expertise that makes Cisco switches the first choice in business networking. Meraki cloud management offers control over a potential thousands of ports when stacked, with built-in multi-site management and zero touch provisioning of connected devices.

Cisco Meraki MS225-24P Switch Quick Specs:

• Ethernet Ports: 24x RJ45, Gigabit, PoE/PoE+
• Fiber Uplink Ports: 4x SFP+, 10 Gigabit
• Additional Ports: 2x stacking, 1x RJ45 management
• PoE: yes, 370W maximum output
• 802.3af PoE, 15.4W per port
• 802.3at PoE+, 25.5W per port
• Switching Capacity: 128 Gbps
• Stacking Bandwidth: 80G
• Stackable: physical (up to 8) and virtual
• Management: via web (Meraki cloud management platform)
• QoS: 802.1p, 8 queues, DSCP to CoS mapping
• Mountable: 1U rack-mountable
• Dimensions: 1.72" x 19.08" x 9.84"

Cisco MS225-24P-HW Cloud-Managed Gigabit PoE Switch Package Contents:

• MS225-24P switch
• Mounting screw kit
• Getting started insert
