Grandstream GSC3506 V2 IP Paging Speaker

Grandstream GSC3506 V2 is an IP paging speaker with multicast support. GSC3506 V2 features a 30W high-fidelity speaker with specially designed acoustic chamber to produce intelligible, full-sounding sounds. In other words, the paging speaker is perfect for offices, schools, hospitals, and many more locations.

GSC3506 V2 is network-connected paging speaker that supports SIP, making it broadly interoperable with VoIP phone systems and services. The paging speaker has numerous I/O connections, including a 2-pin switch-in input port, alarm-in input port, and 3-pin differential line-out port. Power the speaker via POE (Power Over Ethernet). GSC3506 V2 supports up to 802.3bt Class 6 POE++.

© 2024 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Grandstream GSC3506 V2 Quick Specs:

• Connectivity Type: IP/VoIP
• VoIP Protocol: SIP
• Speaker: 30W high-fidelity HD speaker (coaxial)
• Physical Connectors:
• Ethernet: 1× 10/100 RJ45 POE
• USB: 1× USB-A 2.0
• I/O: 1× 2-pin switch-in input, 1× alarm-in input
• Line Out: 1× 3-pin differential line out port
• Power: 1× power port
• POE (Power Over Ethernet):
• POE: 802.3af Class 3
• POE+: 802.3at Class 4
• POE++: 802.3bt Class 6
• Dimensions:
• Diameter: 10.14 in
• Depth: 4.65 in

Grandstream GSC3506 V2 Multicast Paging Speaker Package Contents:

• GSC3506 V2 Speaker
• Mounting Hole Cut-Out Template
• Quick Installation Guide

Grandstream GSC3506 V2 Documentation:

• Grandstream GSC3506 V2 Datasheet
