Hikvision DS-KIS602 Modular IP Video Intercom Kit

Hikvision DS-KIS602 comprises everything you need to get started with Hikvision's network-connected modular video intercom system: Hikvision DS-KD8003-IME1 Intercom with surface mount box, Hikvision DS-KH6320-WTE1 Indoor Station, and Hikvision DS-3E0105P-E/M Switch.

Hikvision DS-KD8003-IME1 is a compact full-duplex intercom with integrated 1080p Full HD video camera and configurable physical button for professional door security in an office, apartment, or similar location. Control the intercom using Hikvision DS-KH6320-WTE1, a video indoor station with large touchscreen display, which lets users in the office or apartment to speak, see, and let in people at the doorway. Because the system is network-connected, it integrates with Hikvision's mobile app to give you video and audio communications and access control wherever you are. The package also includes a 4-port network switch to connect the devices to your LAN.

Hikvision DS-KIS602 Quick Specs:

• Hikvision DS-KD8003-IME1/Surface Intercom:
• Ethernet Port: 10/100
• PoE 802.3af
• Additional Interfaces:
• 1x module connector
• 4x I/O inputs
• 1x debug port
• 2x relays
• 1x tampering alarm
• Video Resolution: up to 1080p
• Field of View: 180°H x 96°V
• Video Codecs: H.264
• Microphone: built-in, omnidirectional
• Speaker: built-in
• Audio Codecs: G.711u
• Operating Temperature: -40°F to 140°F
• Durability Rating: IP65
• Hikvision DS-KH6320-WTE1 Indoor Station:
• Ethernet Port: 10/100
• PoE: 802.3af
• Wi-Fi: 802.11n
• Additional Interfaces:
• 8-ch alarm inputs
• 2x relay outputs
• 1x RS485
• 1x microSD card slot
• Display: 7" 1024x600 color TFT LCD capacitive touchscreen
• Microphone: built-in, omnidirectional
• Speaker: built-in
• Audio Codecs: G.711u

Hikvision DS-KIS602 Modular IP Video Intercom Kit Package Contents:

• Hikvision DS-KD8003-IME1/Surface Intercom
• Hikvision DS-KH6320-WTE1 Indoor Station
• Hikvision DS-3E0105P-E/M Switch

Hikvision DS-KIS602 Documentation:

• Hikvision DS-KIS602 Data Sheet
