Panasonic WV-U2542L 4MP IR Varifocal Outdoor Dome IP Camera

No reviews yet Write a Review
SKU:
WV-U2542L
Availability:
Discontinued - This item is no longer available for purchase.

Have a question?

  • Industry Best Pricing

    Quantity discounts available

  • Friendly Associates

    Pre-sales product and solution advice

  • Expert Tech Support

    Add-on tech support plans available

  • Super Fast Delivery

    Same day shipping on most orders

Panasonic WV-U2542L 4MP IR Varifocal Outdoor Dome IP Camera

Panasonic WV-U2542L is a cost effective IP camera that provides highly detailed security video. Designed for outdoor installation, WV-U2542L uses a 4MP CMOS sensor and varifocal 2.9-7.3 mm lens with 2.5x optical zoom. Use the camera in locations like banks, hospitals, stations, and safe cities — general outdoors surveillance. The camera comes with color night vision technology — excellent low light performance. For situations with no light, use the onboard infrared lights with 65 ft range.

WV-U2542L uses Panasonic iA (Intelligent Auto) technology to adaptively improve video. iA adjusts camera settings in real time in response to changes in the scene — clearer images with no extra effort. Super Dynamic 102dB technology responds to high contrast lighting like headlights — more detail retained. H.265 Smart Coding technology greatly reduces the size of the video feed — longer recording and less storage. Record video in camera using a microSD card or through the network using a NAS or NVR solution.

WV-U2542L has a rugged die cast aluminum body and clear polycarbonate resin dome. It meets the IP66 and IK10 ratings — weather and vandal resistant. It has an extended operating temperature range of -22°F to 122°F. Power it using PoE — simplified infrastructure. WV-U2542L is ONVIF Profile G and Profile T compliant — interoperable with open standards systems.

Panasonic WV-U2542L Quick Specs:

  • Connectivity Type: IP
  • Ethernet Port: 10/100 PoE
  • PoE: 802.3af Class 0
  • Sensor: 1/2.7" CMOS
  • Resolution: up to 4MP @ 30 fps
  • Lens: varifocal 2.9-7.3 mm, f/2.0-3.0
  • Zoom: 2.5x optical
  • Field of View:
    • Horizontal: 43° to 100°
    • Vertical: 24° to 56°
  • Adjustment Angle:
    • Pan: ±180°
    • Tilt: -30° to +85°
    • Yaw: ±100°
  • Video Codecs: H.265, JPEG
  • Minimum Illumination:
    • Color: 0.3 lux
    • B/W: 0.12 lux
    • Infrared: 0 lux
  • Infrared Range: 65 ft
  • Edge Storage: microSD, microSDHC, microSDXC
  • ONVIF: Profile G, Profile T
  • Operating Temperature: -22°F to +122°F
  • Durability Standards: IP66, IK10, NEMA 4X
  • Dimensions:
    • Diameter: 6.06 in
    • Height: 4.06 in
  • Weight: 2.21 lb

Panasonic WV-U2542L Network Security Camera Package Contents:

  • Panasonic WV-U2542L IP Camera
Warranty:
5 Year
