Viking K-1705-IP VoIP Video Entry Phone with Keypad

Viking K-1705-IP is a VoIP entry phone with keypad that includes an analog color CCTV camera. Featuring a 14-gauge 316 stainless steel faceplate with laser-etched graphics, the K-1705-IP resists vandals, including the heavy duty metal keys and call button. Viking has built in an analog video camera with a 1/4" color CMOS sensor to produce 640x480 images at 30 frames per second. The conical pinhole lens covers the whole scene with an 80° horizontal by 60° vertical field of view. K-1705-IP supports the open SIP protocol, and integrates with numerous VoIP platforms, including Asterisk, Switchvox, Cisco UC Manager and 3CX. VoIP integration expands the capabilities and simplifies the management of the entry phone. K-1705-IP is a Class 2 PoE device.

Viking K-1705-IP includes all the entry phone features that make Viking the choice of businesses, apartments, residences and gated locations. The camera is protected by a scratch-resistant polycarbonate window with water-tight gasket. The microphone is omnidirectional and has a water-resistant cloth that protects it. The blue call LED is multi-functional: it helps users find the call button in darkness, flashes during dialing, and is steady to indicate an in-process call. A 26-bit Wiegand input is built-in for use with proximity card readers. You can program up to 1,000 keyless entry codes or proximity card numbers. The package includes a rough-in box and Torx security screws with the necessary drill bit.

Viking K-1705-IP Entry Phone Quick Specs:

• Connectivity Type: VoIP/IP
• Communications Protocol: SIP
• Ethernet Port: 1x 10/100
• PoE: 802.3af Class 2
• Connectors: 14x gel-filled butt connectors
• Camera: analog NTSC
• Sensor: 1/4" color CMOS
• Lens: 2.1mm, conical pinhole
• Video Resolution: up to 640x480 at 30 fps
• Field of View: 80°H x 60°V, 100° diagonal
• Audio Codecs: G.711μ/a, G.722
• Operating Temperature: -40°F - 140°F
• Dimensions: 5.5" x 6.5" x 2.6"
• Finish: brushed stainless steel
• Mounting: flush or surface
• Surface Mount: requires Viking VE-6x7 box

Viking K-1705-IP VoIP Entry Phone Package Contents:

• K-1705-IP phone
• Rough-in box
• 4x T-10 Torx security screws and drive bit
